當前位置：鋁條丁基膠涂布機使用的特點介紹
時間：2023-09-25 來源：http://www.hebeiruizhi.com/ 發布人：昌盛機械
1、丁基膠涂布機為中空玻璃出產的首要必選設備，為半主動膠條涂布機，即人工持鋁距離框進行操作，將鋁距離框放在傳送帶上，人工持鋁距離框隨傳送帶運行，當鋁距離框經過傳感器時，傳送壓輪及打膠閥將按設定程序主動運行，即氣缸動作，壓輪壓下，壓送鋁距離框進行;待鋁距離框抵達打膠頭時開端打膠，將膠均勻地涂在鋁距離框上，當距離框另一側快要抵達壓輪時，壓輪抬起，離開打膠頭時，膠閥主動停止打膠。
1. The butyl adhesive coating machine is the primary and necessary equipment for the production of insulating glass. It is a semi-active adhesive strip coating machine, which manually holds the aluminum distance frame for operation. The aluminum distance frame is placed on the conveyor belt, and the manual holding aluminum distance frame runs with the conveyor belt. When the aluminum distance frame passes through the sensor, the conveying pressure wheel and glue valve will operate actively according to the set program, that is, the cylinder will act, the pressure wheel will press down, and the aluminum distance frame will be pressed; When the aluminum distance frame reaches the gluing head, start gluing and evenly apply the glue to the aluminum distance frame. When the other side of the distance frame is about to reach the pressing wheel, the pressing wheel is lifted, and when it leaves the gluing head, the glue valve actively stops gluing.
2、選用人機界面顯示屏便于操作，體系以PLC為操控中心，由光電傳感PLC機、中文操控終端、PLC主動轉換。按鈕開關等電器元件組成，功用強大、作業牢靠、操作簡單主動化程度較高。
2. The human-machine interface display screen is selected for easy operation, and the system takes PLC as the control center, with photoelectric sensing PLC machine, Chinese control terminal, and PLC active conversion. The button switch and other electrical components are composed of powerful functions, reliable operation, simple operation, and high degree of automation.
3、鋁條丁基膠涂布機選用目前國內非常大缸徑?195膠缸，裝膠容量大，非常大較限確保連續出產時刻，進步作業效率。選用較氣動增壓體系，充沛確保膠頭出膠壓力衡定，避免了打膠粗細不勻，斷膠現象。選用4段變頻調速，非常大較限照料操作工人熟練程度，進步作業效率。
3. Is the aluminum strip butyl adhesive coating machine currently equipped with a very large cylinder diameter in China? 195 rubber cylinder, with a large loading capacity, ensures continuous production time and improves work efficiency due to its extremely large and limited capacity. Adopting an advanced pneumatic pressure boosting system, it ensures that the pressure of the adhesive head is constant, avoiding uneven thickness and breakage of the adhesive. The use of 4-stage variable frequency speed regulation greatly limits the proficiency of care operators and improves work efficiency.
4、鋁條丁基膠涂布機主要功能有：
4. The main functions of the aluminum strip butyl adhesive coating machine are:
1恣意設置主動加熱時刻
1. Set the active heating time arbitrarily
2無膠啟動緊急信號提示
2. Emergency signal prompt for glue free start
3膠頭、膠缸主動加熱功用
Active heating function of 3 rubber heads and rubber cylinders
4主動待機功用：減少工人值守時刻，進步作業效率5在手動狀態下可打圓弧。
4. Active standby function: reduces worker duty hours and improves work efficiency. 5. In manual mode, it can create arcs.
5、選用不銹鋼作業臺面，充沛確保設備外觀及整理方便。
5. Select stainless steel work surface to ensure convenient equipment appearance and organization.
技術參數：
Technical parameters:
電源：
Power supply:
總功率：
Total power:
運送速度：
Delivery speed:
打膠溫度：
Gluing temperature:
氣動壓力：0.5—
Pneumatic pressure: 0.5-
擠膠壓力：8—
Squeezing pressure: 8-
膠頭可調范圍：6—
Adjustable range of rubber head: 6-
外形尺寸：
Overall dimensions:
以上就是立式丁基膠涂布機廠家為大家介紹的內容，感謝您在百忙之中查看我公司的信息內容http://www.hebeiruizhi.com ，如果您想要了解的更多，歡迎您來電進行咨詢!
The above is the content introduced by the manufacturer of the vertical butyl adhesive coating machine. Thank you for taking the time to check our company's information http://www.hebeiruizhi.com If you want to learn more, welcome to call for consultation!
